A high-speed board to board interconnect solution for PCIE 3.0 and SAS interfaces with data transfer up to 21 Gbps.

Part type	Description	Total number of contacts	Current max. [A]	Insulator withstanding voltage min. [V]	Contact resistance max. [mΩ]	Insulation resistance min. [MΩ]	Operating temperature [°C]	*Enlarge using the cursor*
Part type	Description	Total number of contacts	Current max. [A]	Insulator withstanding voltage min. [V]	Contact resistance max. [mΩ]	Insulation resistance min. [MΩ]	Operating temperature [°C]	*Enlarge using the cursor*
271 Series (150 kB)	high speed card edge connector compliant with SAS 3.0 and PCIe 3.0 standards, plug data rate: 16 Gbps contact termination: vertical contact plating: gold Available versions: 271 Series	68		500	30	1000	-55 – +80
272 Series (150 kB)	high speed card edge connector compliant with SAS 3.0 and PCIe 3.0 standards, receptacle, black color data rate: 16 Gbps contact termination: vertical press-fit contact plating: gold Available versions: 272 Series	68		500	30	1000	-55 – +80
273 Series (150 kB)	high speed card edge connector compliant with SAS 3.0 and PCIe 3.0 standards, receptacle data rate: 16 Gbps contact termination: vertical SMT contact plating: gold Available versions: 273 Series	29		500	30	1000	-55 – +80
370 Series (163 kB)	high speed card edge connector compliant with SAS 3.0 and PCIe 3.0 standards, receptacle without latch, black color data rate: 21 Gbps contact termination: vertical SMT contact plating: gold Available versions: 370 Series	20, 100, 200	3.1	750	15	1000	-55 – +125
470 Series (189 kB)	high speed card edge connector compliant with SAS 3.0 and PCIe 3.0 standards, plug, black color data rate: 18 Gbps contact termination: vertical SMT contact plating: gold Available versions: 470 Series	100, 160	2.9	900	10	25000	-20 – +105
472 Series (178 kB)	high speed card edge connector compliant with PCIe 3.0 standard, plug, black color data rate: 19 Gbps contact termination: vertical SMT contact plating: gold Available versions: 472 Series	100, 150	1.4	200	25	10000	-55 – +125
473 Series (178 kB)	high speed card edge connector compliant with PCIe 3.0 standard, receptacle, black color data rate: 19 Gbps contact termination: right angle SMT contact plating: gold Available versions: 473 Series	100, 150	1.4	200	25	10000	-55 – +125
